Computed Radiography
Trimax CR System (60 PPH)
A compact CR plate reader that brings an existing film-based X-ray room onto a digital workflow — tabletop or vertical setup, 60 plates/hour, with a self-install option.
Key Specifications
- Throughput
- 60 plates/hour (selectable 30/45/60 PPH)
- Monitor
- 21" LED
- DICOM printing
- Available
- Image preview time
- Under 30 seconds
Full Specifications
| Throughput | 60 plates/hour (selectable 30/45/60 PPH) |
| Monitor | 21" LED |
| DICOM printing | Available |
| Image preview time | Under 30 seconds |
| Configuration | Tabletop, desktop-floor, or mobile (back-of-vehicle); horizontal or vertical |
| Cassette sizes | 8×10in · 10×12in · 11×14in · 14×14in · 14×17in · 14×33in · 24×30cm · 15×30cm |
| Self-install | Carton to first image in under 90 minutes |
| Full-service install | Available via certified technician |
| Self-service | Three field-replaceable units for fast self-repair |
About This Product
For a room that already has a working generator but is still shooting film, the Trimax CR reader is the fastest route to a digital workflow — no need to replace the generator itself. It runs at up to 60 plates/hour (selectable at 30/45/60 PPH to match the room's actual volume), sets up horizontally or vertically to fit tight spaces, and can be self-installed from carton to first image in under 90 minutes.
