Digital Radiography Solutions

Eco DR System — Ceiling-Free, Single Detector

An affordable full-room digital X-ray built around one detector that handles every position — chest, abdomen, limbs, and joints — instead of a separate detector for each stand.

Key Specifications

Models / power output: 20kW · 40kW · 50kW · 80kW
Line nominal phase: Single/three-phase 230/440VAC (20/40kW) · three-phase 440VAC (50/80kW)
Line voltage: ±10%, 50/60Hz
kV range: 40–125kV (20/40kW) · 40–150kV (50/80kW)
mA range: 10–250mA up to 10–1,000mA depending on tier

Enquire About This Product Download Brochure

Full Specifications

Models / power output	20kW · 40kW · 50kW · 80kW
Line nominal phase	Single/three-phase 230/440VAC (20/40kW) · three-phase 440VAC (50/80kW)
Line voltage	±10%, 50/60Hz
kV range	40–125kV (20/40kW) · 40–150kV (50/80kW)
mA range	10–250mA up to 10–1,000mA depending on tier
mAs range	0.1–320mAs
Timer range	0.01–10s
Inverter frequency	220kHz

About This Product

The Eco DR System is the economical route into a full digital radiography room: a single flat-panel detector, mounted on a ceiling-free counterbalanced stand that travels a floor rail, handles chest, abdominal, hand, leg, neck, joint, and kidney/uterus/bladder positioning without swapping equipment. Available across four power tiers (20kW–80kW), it's a strong fit for a facility that wants a complete room without the cost of a ceiling-suspended or dual-detector setup.
