Digital Radiography Solutions

Floor-Standing Digital X-Ray — CF Auto Premium

A premium floor-standing alternative to a ceiling-mounted room, for facilities that can't install an overhead rail — a 9.7" touch console, a 6-way floating table, and upgradable dual detectors.

Key Specifications

Models / power output: 630S (50kW) · 800S (80kW) · 1000S (80kW)
mAs range: 0.1–630mAs / 0.1–800mAs / 0.1–1,000mAs
kV range: 40–150kV (all tiers)
mA range: 10–630mA / 10–800mA / 10–1,000mA
Line: Three-phase 440V ±10%, 50/60Hz

Enquire About This Product Download Brochure

Full Specifications

Models / power output	630S (50kW) · 800S (80kW) · 1000S (80kW)
mAs range	0.1–630mAs / 0.1–800mAs / 0.1–1,000mAs
kV range	40–150kV (all tiers)
mA range	10–630mA / 10–800mA / 10–1,000mA
Line	Three-phase 440V ±10%, 50/60Hz
Inverter frequency	220kHz
Time range	1ms–10,000ms
Exposure mode	Manual & automatic

About This Product

For sites where installing an overhead ceiling rail isn't possible, the CF Auto Premium delivers a comparably capable room on a floor-standing frame — up to 1,000mA, a six-way floating table rated to 250kg, and an intuitive 9.7" touch console that rotates orientation on the fly. Dual flat-panel detector support (wired or wireless, 14"×17" or 17"×17") and an advanced panoramic-imaging mode that merges upper-limb, lower-limb, and spine captures round out the premium tier of our fixed radiography line.
